CORONA TREATER ROLLS
New Rolls, Recoating, and Recovery for Any Corona Treater
QC Electronics provides new corona treater rolls and recoats existing rolls for any brand of corona treater. Ceramic, epoxy, and silicone coverings. Tried, true, and tested. Guaranteed performance.
Get a Quote → Call 800-366-1988Any BrandNew Rolls
& Recoating
& Recoating
100%Dielectric Tested
Before Shipment
Before Shipment
7Covering
Options
Options
WIAmerican
Made
Made
WHAT WE DO
Complete Roll Services for Any Corona Treater
Whether you need a brand-new roll built, an existing roll stripped and recoated, or a spare roll for your inventory—we handle it all. Any brand, any size, any covering type.
New Roll Manufacturing
Brand-new corona treater rolls to your exact specifications: core material, diameter, face width, and covering type. Designed for your specific treater and application.
Strip & Recoat
Send us your worn roll. We strip the existing covering, inspect the core, journals, and shafts, and apply a fresh coating, returning it to like-new condition at a fraction of the cost of a new roll.
Silicone Sleeving
Non-stick silicone elastomer sleeving that releases tacky materials and prevents wrap-ups. Available for rolls from 2″ to 10″ diameter. Quick replacement for covered roll systems.
Shaft & Journal Inspection Included
Every recoat includes a full inspection of the roll core, shaft, and journals for wear and damage. If repairs are needed, we will let you know so that your roll comes back ready to run, not just recoated.
ROLL COVERINGS
8 Specialty Coverings for Every Application
Our roll coverings are available in a wide variety of surface finishes and materials. Every roll is 100% corona treater tested prior to shipment—guaranteed performance with the strongest warranty on the market.
| CERAMIC COVERINGS | ||
| Conductive Ceramic | For bare roll systems. Protects aluminum rollers from surface oxidation and knife cuts while maintaining conductivity required for bare roll corona discharge. | Bare roll systems |
| Nonconductive Ceramic | The standard ceramic covering for covered roll applications. Prevents oxidation and knife cuts in a nonconductive formulation designed for covered roll corona discharge. Available for steel and aluminum roller cores. | Covered roll systems |
| High Dielectric Ceramic | High dielectric strength ceramic for demanding applications like skip treating where standard coverings break down. | Skip treating / harsh environments |
| Extreme Duty Ceramic | Maximum dielectric strength and high-temperature capability for the harshest corona treater environments. | Extreme duty / high temp |
| EPOXY | ||
| Epoxy | Ultra robust coating for heavy-duty operations requiring maximum durability. | Heavy duty |
| SILICONE | ||
| Silicone Coating | Applied directly to the roll surface for maximum durability and adhesion. More robust than sleeving with a longer service life. Non-stick release properties prevent wrap-ups. | Covered roll |
| Silicone Sleeving | Removable elastomer sleeve that slides over the roll. Quick to replace in the field without sending the roll out. Heat resistant to 400°F. FDA compliant. Diameters from 1.5″ to 10″. | Covered roll / quick replacement |
CHOOSING THE RIGHT COVERING
Not Sure Which Coating You Need?
The right roll covering depends on your treater configuration, substrate, power level, and operating environment. Here’s a quick guide:
→Bare roll system? Conductive ceramic protects your aluminum roller while maintaining the conductivity bare roll systems require
→Covered roll system? Nonconductive ceramic is the standard covering. Same surface protection as conductive, designed for covered roll corona discharge. Available for steel and aluminum cores
→Skip treating or harsh environment? High dielectric ceramic handles demanding applications
→Extreme duty / high temperature? Extreme duty ceramic for the harshest conditions
→Heavy duty operations? Epoxy coating for maximum durability
→Tacky materials causing wrap-ups? Silicone sleeving releases sticky substrates and prevents downtime
→Want silicone but need more durability? Silicone coating is applied directly to the roll and lasts longer than sleeving. Choose sleeving if you need quick field replacement; choose coating if you want maximum service life
HOW TO ORDER
Get Your Roll Quote in 3 Steps
01
Tell Us What You Need
New roll or recoat? Give us the type of electrode and roll core, roll dimensions (face width × diameter), and current covering type. If you’re not sure, send us a photo and we’ll identify the station type and roll coating.
02
We Recommend & Quote
Our team recommends the right covering for your application and provides a quote. For recoats, we’ll assess whether your core is suitable for recovering or if a new roll is a better investment.
03
100% Corona Tested
Every roll—brand-new or recoated—is 100% corona treater tested before it ships. You receive a roll that’s been proven under actual corona discharge conditions, not just visually inspected.
RELATED SERVICES
GET STARTED
Need a New Roll or Recoat?
Tell us your roll dimensions and the type of electrode and ground roll. We’ll quote a new roll, a recoat, or both.
